Placa base intel® h610 con diseño vrm digital de 6+1+1 fases híbridas, diseño pcie 4.0 *, gen3 x4 m.2, intel® gbe con cfosspeed, resistencia antiazufre, ventilador inteligente 6.

admite procesadores intel® core™ series de 13.ª y 12.ª generación.

Ddr4 sin búfer sin ecc de doble canal, 2 dimm.

Diseño vrm digital híbrido 6+1+1.

lan intel® gbe con software acelerador de internet cfosspeed.

Nvme pcie 3.0 x4 m.2.

Condensadores de audio de alta calidad y protector contra ruido de audio.

Smart fan 6 cuenta con múltiples sensores de temperatura y cabezales de ventilador híbridos con fan stop.

Centro de app de gigabyte, uso sencillo y fácil.

Diseño de resistencias anti-Azufre

Procesador.

Lga1200 package:.

11Th generation intel® core™ i9 processors / intel® core™ i7 processors / intel® core™ i5 processors.

10Th generation intel® core™ i9 processors / intel® core™ i7 processors / intel® core™ i5 processors / intel® core™ i3 processors/ intel® pentium® processors / intel® celeron® processors.

L3 cache varies with cpu.

(Please refer to cpu support list for more information.).

Chipset.

Intel® h470 express chipset.

Memoria.

11Th generation intel® core™ i9/I7/I5 processors:.

Support for ddr4 3200/3000/2933/2666/2400/2133 mhz memory modules.

10Th generation intel® core™ i9/I7 processors:.

Support for ddr4 2933/2666/2400/2133 mhz memory modules.

10Th generation intel® core™ i5/I3/Pentium®/Celeron® processors:.

Support for ddr4 2666/2400/2133 mhz memory modules.

2 x ddr4 dimm sockets supporting up to 64 gb (32 gb single dimm capacity) of system memory.

Dual channel memory architecture.

Support for ecc un-Buffered dimm 1Rx8/2Rx8 memory modules (Operate in non-Ecc mode).

Support for non-Ecc un-Buffered dimm 1Rx8/2Rx8/1Rx16 memory modules.

Support for extreme memory profile (Xmp) memory modules.

(Please refer memory support list for more information.).

Gráficos integrados.

Integrated graphics processor-Intel® hd graphics support:.

1 x hdmi port, supporting a maximum resolution of 4096X2160@30 hz.

*Support for hdmi 1.4 version and hdcp 2.3.

1 x d-Sub port, supporting a maximum resolution of 1920X1200@60 hz.

*The d-Sub port is only available with the 10Th generation processors.

(Graphics specifications may vary depending on cpu support.).

Audio.

Realtek® audio codec.

High definition audio.

2/4/5.1/7.1-Channel.

*You can change the functionality of an audio jack using the audio software.

To configure 7.1-Channel audio, access the audio software for audio settings.

lan.

Realtek® gbe lan chip (1 gbps/100 mbps/10 mbps).

Puertos de expansión.

Cpu:.

1 x pci express x16 slot, supporting pcie 3.0 and running at x16.

Chipset:.

1 x pci express x1 slot, supporting pcie 3.0 and running at x1.

Interfaz de almacenamiento.

Chipset:.

1 x m.2 connector (Socket 3, m key, type 2280 sata and pcie 3.0 x4/X2 ssd support).

4 x sata 6Gb/S connectors.

Raid 0, raid 1, raid5, and raid 10 support for nvme ssd storage devices.

Raid 0, raid 1, raid5, and raid 10 support for sata storage devices.

Usb.

Chipset:.

4 x usb 3.2 gen 1 ports (2 ports on the back panel, 2 ports available through the internal usb header).

6 x usb 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal usb header).

Conectores internos de e/S.

1 x 24-Pin atx main power connector.

1 x 8-Pin atx 12V power connector.

1 x cpu fan header.

1 x system fan header.

1 x rgb led strip header.

1 x m.2 socket 3 connector.

4 x sata 6Gb/S connectors.

1 x front panel header.

1 x front panel audio header.

1 x usb 3.2 gen 1 header.

1 x usb 2.0/1.1 header.

1 x trusted platform module header (For the gc-Tpm2.0 spi/Gc-Tpm2.0 spi 2.0 module only).

1 x serial port header.

1 x clear cmos jumper.

Conectores del panel trasero.

1 x ps/2 keyboard/Mouse port.

1 x d-Sub port.

1 x hdmi port.

2 x usb 3.2 gen 1 ports.

4 x usb 2.0/1.1 ports.

1 x rj-45 port.

3 x audio jacks.

Controlador de e/S.

Ite® i/O controller chip.

Monitorización h/W.

Voltage detection.

Temperature detection.

Fan speed detection.

Fan fail warning.

Fan speed contro.

*Whether the fan speed control function is supported will depend on the cooler you install.

bios.

1 x 128 mbit flash.

Use of licensed ami uefi bios.

Pnp 1.0A, dmi 2.7, wfm 2.0, sm bios 2.7, acpi 5.0.

Características únicas.

Support for app center.

*Available applications in app center may vary by motherboard model.

Supported functions of each application may also vary depending on motherboard specifications.

@Bios.

Ambient led.

Easytune.

Smart backup.

System information viewer.

Support for q-Flash.

Support for xpress install.

Software incluido.

Norton® internet security (Oem version).

Lan bandwidth management software.

Sistema operativo.

Support for windows 11 64-Bit.

Support for windows 10 64-Bit.

Diseño.

Micro atx form factor.

22.6Cm x 18.5Cm

GARANTÍA: 1 AÑO
