Acces point doble banda.

450Mbps en 2.4 ghz.

867 mbps en 5 ghz.

Integrado en omada sdn, administracion centralizada de la nube y monitoreo inteligente.

Compatibilidad con poe (Adaptador poe no incluido).

Caracteristicas de hardware.

interface gigabit ethernet (Rj-45) port×1 (Support ieee802.3Af/At poe and passive poe).

Cerradura de seguridad fisica yes.

Boton reset.

Fuente de alimentacion.

• 802.3Af/At poe.

• 48V passive poe (+4,5Pins.

-7,8Pins.

Poe adapter is not included).

Consumo de energia eu: 9.7W.

us: 12.1W.

dimensiones (W x d x h) 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm).

Tipo de antena 3 internal omni.

• 2.4 ghz: 4 dbi.

• 5 ghz: 5 dbi.

montaje ceiling /Wall mounting (Kits included).

Características inalambricas.

estandares inalambricos ieee 802.11Ac/N/G/B/A.

Frecuencia 2.4 ghz and 5 ghz.

Tasa de senal.

• 5 ghz:Up to 867 mbps.

• 2.4 ghz:Up to 450 mbps.

Funciones inalambricas.

• multiple ssids (Up to 15 ssids, 8 for 2.4Ghz band, 7 for 5Ghz band).

• enable/Disable wireless radio.

• automatic channel assignment.

• transmit power control (Adjust transmit power on dbm).

• qos(Wmm).

• seamless roaming.

• omada mesh.

• band steering.

• load balance.

• mu-Mimo.

• airtime fairness.

• beamforming.

• rate limit.

• reboot schedule.

• wireless schedule.

• wireless statistics based on ssid/Ap/Client.

Seguridad inalambrica.

• captive portal authentication.

• access control.

• wireless mac address filtering.

• wireless isolation between clients.

• ssid to vlan mapping.

• rogue ap detection.

• 802.1X support.

Potencia de transmision.

• ce:.

and #8804;20 dbm(2.4 ghz, eirp).

and #8804;23 dbm(5 ghz, eirp).

• fcc:.

and #8804;24 dbm(2.4 ghz).

and #8804;22 dbm(5 ghz).

Administración.

omada app yes.

Centralized management.

• omada hardware controller oc300.

• omada hardware controller oc200.

• omada software controller.

• omada cloud-Based controller.

Cloud access yes, through.

• oc300.

• oc200.

• omada software controller.

• omada cloud-Based controller.

alertas de correo electrónico yes.

Led on/Off control yes.

Management mac access control yes.

Snmp v1,V2C.

System logging local/Remote syslog local/Remote syslog.

Ssh yes.

Web-Based management http/Https.

L3 management yes.

Multi-Site management yes.

Management vlan yes.

Zero-Touch provisioning yes.

Requiring the use of omada cloud-Based controller.

Otros.

certificacion ce, fcc, rohs.

Contenidos del paquete.

• ac1350 wireless mu-Mimo gigabit ceiling mount access point eap223.

• mounting kits.

• installation guide.

requisitos del sistema microsoft windows xp, vista, windows 7, windows 8, windows10, windows11, linux.

Ambiente.

• operating temperature: 0–40 and #8451.

(32–104 and #8457;).

• storage temperature: -40–70 and #8451.

(-40–158 and #8457;).

• operating humidity: 10–90% rh non-Condensing.

• storage humidity: 5–90% rh non-Condensing.

GARANTÍA: 2 AÑOS
